GD10
Desking done right. The GD10 is a bit of a masterpiece. Made from oak and handcrafted in Bolton, GD10 keeps things simple. A design that celebrates traditional, with a range of cleverly concealed fixtures to suit modern needs. An antidote for bland design.
Product range
Dining
GD10A1
Four Leg 751mm High
GD10E1
Six Leg 751mm High
Poseur
GD10C1
Four Leg 1071mm High
GD10G1
Six Leg 1071mm High
Bench Seating
GD1005BS
Four Leg 450mm High
GD1010BS
Four Leg 450mm High
GD1014BS
Six Leg 450mm High
Features
CONSIDERATIONS
- Available in a selection of lengths, widths & heights
- Available with optional cable management
- Available with oak top and Lam/Lino top
- Available with optional, over-desk power bars.
- Produced in K.D. form to allow assembly on site
MATERIALS
The standard tops, end frames and rails are manufactured from engineered hardwood that are made-up from finger-jointed staves. This provides the ‘block board’ appearance.
Each wooden component is cut from those panels, laminated using Polyurethane adhesive and then machined to detail. End frames incorporate traditional mortise and tenon joints for strength, whilst the skirt rails bordering the underside of the work surfaces are mitered in the corners to improve the tables’ aesthetics.
All wooden components are finished with three coats of ‘Tung Oil’ – a natural, sustainable air drying oil produced from seeds that provides an even, deep transparent coating that hardens upon exposure to air and is easily maintained.
The skirt rails and support battens pre-fitted to the work surface are attached using ‘hi-lo construction’ screws, providing a strong, flush fix.
All other elements are attached
using steel, metric Allen-key headed machine screws that locate into course threaded screw-in inserts, providing a substantial metal-to-metal fix that maintains their hold even after multiple assembly / dis-assembly operations.
End and centre frames are also connected to the top panels using 6mm thick Mild Steel connector plates, used to spread the load. These are precision laser cut and have a durable epoxy powder coated finish
LEG FINISHES
Oak
